Red Large On-Off Rectangle Rocker Switch DPST High Quality
£1.98 – £8.70
Loading...
Description
Red Large On-Off Rectangle Rocker Switch DPST High Quality
On / Off heavy duty rocker switch
The switch offers a high switching current in a compact design
It is snap mounted with a high mechanical life in a rugged Nylon 66 housing.
It offers long life at heavy loads with industry standard mounting dimensions
Can be used in a variety of applications, such as Vacuum cleaners, water dispensers and extension sockets.
Includes:
1 X Heavy duty rocker switch with Red button (Choose quantity from the options above)
Product details:
- Terminal: Silver plated Brass
- Rating: 20A 125VAC / 15A 250VAC
- Contact configuration: DPST
- Contact Resistance: 35 mOhm max.
- Housing Colour: Black
- Button Colour: Red (Black and Green are available – see our shop)
- 6.3mm quick connect terminals
- Dimensions: 39mm x 31mm x 25.3mm (H x L x W)
- Panel cutout: 28.5mm x 21.5mm
- Certifications: CE, CQC, TUV, SGS
- Part number: ASSRS002
On / Off heavy duty rocker switch
The switch offers a high switching current in a compact design
It is snap mounted with a high mechanical life in a rugged Nylon 66 housing.
It offers long life at heavy loads with industry standard mounting dimensions
Can be used in a variety of applications, such as Vacuum cleaners, water dispensers and extension sockets.
Includes:
1 X Heavy duty rocker switch with Red button (Choose quantity from the options above)
Product details:
- Terminal: Silver plated Brass
- Rating: 20A 125VAC / 15A 250VAC
- Contact configuration: DPST
- Contact Resistance: 35 mOhm max.
- Housing Colour: Black
- Button Colour: Red (Black and Green are available – see our shop)
- 6.3mm quick connect terminals
- Dimensions: 39mm x 31mm x 25.3mm (H x L x W)
- Panel cutout: 28.5mm x 21.5mm
- Certifications: CE, CQC, TUV, SGS
- Part number: ASSRS002
We pride ourselves in producing the highest quality components available. We also aim for the highest standards of customer service.Please contact us if you have any questions about our products
We pride ourselves in producing the highest quality components available. We also aim for the highest standards of customer service.Please contact us if you have any questions about our products
Additional information
| Quantity (Pack Size) | 1, 2, 3, 4, 5 |
|---|
